Chapter 4 ELECTRICAL SIGNALS
4.6 SELF-SERVICE MASTER BOARD (PK-267)
XJ1
No. Signal Name Direction Opposite Side
1
DC+5V -
2 GND -
3,4,5,6 Membrane key control signal ←→
PK-266 XJ3/XJ4
XJ2
No. Signal Name Direction Opposite Side
1,2,3,4,5,6
Key scan
KS0 - 5
→
7,8,9,10,11,12
Key data
KD0 - 5
←
Membrane key
4-12 UNI-7 Service Manual
