ISHIDA UNI-7 - Scale Board (PK-999) Signals

Chapter 4 ELECTRICAL SIGNALS
4.9 SCALE BOARD (PK-999)
XJ2
No. Signal Name Direction Opposite Side
1 D#
2 D
3 DC+12V
4 GND
5 FG
6 Not connected
7 Not connected
8 Not connected
･PK-260
UNI-7 Service Manual 4-17
