Chapter 2 ASSEMBLY DRAWINGS

Parts List (Bench Type)

NO. PART NAME Q'TY NO. PART NAME Q'TY

1 GUIDE PLATTER 1 38 PK-261 1

2 PLATTER 1 39 ACCESSORY PCB SUPPORT 2

3 CASE MAIN UPPER 1 40 BRACKET LCD 1

4 COVER PRINTER UPPER 1 41 LCD TP 1

5 COVER HINGE UPPER 1 42 CASE FRONT CONTROL 1

6 COVER HINGE LOWER 1 43 MEMBRANE 1

7 PLATTER SUPPORT 1 44 PRINTER PLATE 1

8 BLOCK HINGE PLATTER 2 45 CLEAR SHEET 1

9 RUBBER 5 46 BRACKET CONNECTOR 1

10 BRACKET PLATTER SUPPORT 1 47 WIRELESS BOARD 1

11 LOAD CELL 1 48 HARNESS 'C4' SWITCH POWER 1

12 BRACKET LOAD CELL 1 49 COVER SWITCH 1

13 CASE A/D BOARD 1 50 COVER LAN PORT 1

14 A/D BOARD 1 51 ANTENNA 1

15 SHEET DOUBLE TAPE 2 52 COVER BRACKET CONNECTOR 1

16 SCREW 'SEAL' HEXA 1 53 BASE 1

17 SCREW 'SEAL' 1 54 BUSH NG 1

18 PK-260 1 55 PLATE B RS232C 1

19 HARNESS 'C4' FRONT LCD 1 56 PLATE B MAGNET IC 1

20 HARNESS 'C4' REAR LCD 1 57 BLOCK B HINGE SIDE COVER 1

21 HARNESS 'C4' SENSOR 1 58 FOOT ADJUST 4

22 HARNESS 'C2' HEAD 1 59 COVER SIDE 1

23 HARNESS 'S2' MOTOR 1 60 COVER HARNESS 1

24 ACCESSORY PCB SUPPORT 4 61 PK-263 1

25 HARNESS 'C2' CASSETTE 1 62 LCD 1

26 HARNESS 'S2' 24V DC POWER 1 63 CASE REAR COVER 1

27 HARNESS 'S2' 5V POWER 1 64 PANEL REAR 1

28 HARNESS 'C2' A/D 1 65 POWER 1

29 BRACKET LEVEL 1 66 BRACKET POWER 1

30 LEVEL UNIT 1 67 CAP 4

31 FRAME LEVEL 1 68 HARNESS 'C2' POWER 1

32 LENS LEVEL 1 69 KEY SHEET 1

33 BRACKET TOR

UE HINGE 1 70 NAME PLATE SPEC 1

34 HINGE L 1 71 STICKER 'M' 1

35 HINGE R 1 72 STICKER LOCATION OUTPUT 1

36 ACCESSORY CLAMP 1 73 USB GASKET 1

37 CASE REAR CONTROL 1

2-2 UNI-7 Service Manual

Other manuals for ISHIDA UNI-7

User Manual309 pages

Questions and Answers:

Need help?

Do you have a question about the ISHIDA UNI-7 and is the answer not in the manual?

ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
