ISHIDA UNI-7 Service Manual

Chapter 2 ASSEMBLY DRAWINGS
Parts List (Pole Type)
NO. PART NAME Q'TY NO. PART NAME Q'TY
1 GUIDE PLATTER 1 45 BRACKET CONNECTOR 1
2 PLATTER 1 46 WIRELESS BOARD 1
3 CASE MAIN UPPER 1 47 HARNESS 'C4' SWITCH POWER 1
4 COVER PRINTER UPPER 1 48 COVER SWITCH 1
5 COVER HINGE UPPER 1 49 COVER LAN PORT 1
6 COVER HINGE LOWER 1 50 ANTENNA 1
7 PLATTER SUPPORT 1 51 COVER BRACKET CONNECTOR 1
8 BLOCK B HINGE PLATTER 2 52 BASE 1
9 RUBBER 5 53 BUSH NG 1
10 BRACKET PLATTER SUPPORT 1 54 PLATE B RS232C 1
11 LOAD CELL 1 55 PLATE B MAGNET IC 1
12 BRACKET LOAD CELL 1 56 BLOCK B HINGE SIDE COVER 1
13 CASE A/D BOARD 1 57 FOOT ADJUST 1
14 A/D BOARD 1 58 COVER SIDE 4
15 KEY SHEET 2 59 COVER HARNESS 1
16 SCREW 'SEAL' HEXA 1 60 POWER 1
17 PK-260 1 61 BRACKET POWER 1
18 HARNESS 'C2' 5V POWER 1 62 CASE REAR POLE DISPLAY 1
19 HARNESS 'C4' REAR LCD POLE 1 63 PLATE B BRACKET POLE 1
20 HARNESS 'C4' FRONT LCD 1 64 BRACKET POLE STAND 1
21 HARNESS 'C4' SENSOR 1 65 POLE STAND 1
22 HARNESS 'C2' HEAD 1 66 CASE LINK POLE 1
23 HARNESS 'S2' MOTOR 1 67 PLATE LINK POLE 4
24 ACCESSORY PCB SUPPORT 4 68 CASE REAR POLE DISPLAY 1
25 HARNESS 'C2' 24V DC POWER 1 69 PK-263 1
26 HARNESS 'C2' CASSETTE 1 70 LCD 1
27 HARNESS 'C2' A/D 1 71 CASE FRONT POLE DISPLAY 1
28 BRACKET LEVEL 1 72 SHEET DISPLAY PANEL 1
29 LEVEL UNIT 1 73 SCREW 'SEAL' 1
30 FRAME LEVEL 1 74 HARNESS 'C2' POWER 1
31 LENS LEVEL 1 75 STICKER 'M' 1
32 BRACKET TORQUE HINGE 1 76 NAME PLATE SPEC 1
33 HINGE L 1 77 STICKER LOCATION OUTPUT 1
34 HINGE R 1 78 USB GASKET 1
35 ACCESSORY CLAMP 1 79 SHEET DOUBLE TAPE 1
36 CASE REAR CONTROL 1 80 VIBRATION MOTOR 1
37 PK-261 1 81 BRACKET LCD 1
38
ACCESSORY PCB SUPPORT
1
39 BRACKET LCD 2
40 LCD TP 1
41 CASE FRONT CONTROL 1
42 MEMBRANE 1
43 KEYBOARD ASSEMBLY 1
44 CLEAR SHEET 1
2-4 UNI-7 Service Manual

ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
