ISHIDA UNI-7 Service Manual

Chapter 2 ASSEMBLY DRAWINGS
Parts List (Elevated Single Printer type)
NO. PART NAME Q'TY NO. PART NAME Q'TY
1 LCD SHEET 1 47 PLATTER SUPPORT 1
2 CASE FRONT POLE DISPLAY 1 48 BRACKET PLATTER SUPPORT 1
3 LCD 1 49 LOADCELL 1
4 BRACKET LCD 2 50 BRACKET LOADCELL 1
5 ACCESSROY PCB SUPPORT 4 51 COVER HARNESS 1
6 PWB PK-263* 1 52 PWB PK-260* 1
7 CASE REAR POLE 1 53 SHIELD PLATE 1
8 HINGE R 2 54 BASE 1
9 COVER JOINT REAR 1 55 PLATE B MAGNETIC 1
10 SHEET DISPLAY PANEL 1 56 HARNESS 'C2' POWER ASSEMBLY 1
11 SHEET KEY BOARD-PLU 1 57 PLATE B RS232C 1
12 SHEET KEY BOARD 1 58 BRACKET TORQUE HINGE 1
13 KEY BOARD MEMBRANE 1 59 COVER FRONT ELEVATE 1
14 CASE FRONT CONTROL 1 60 POWER SUPPLY 1
15 LCD TOUCH 1 61 BRACKET POWER 1
16 SHEET DOUBLE TAPE 1 62 CASE REAR POLE 1
17 GASKET 115mm 1 63 COVER BRACKET CONNECTOR 1
18 COLLAR SPACER 4 64 COVER SWITCH 1
19 PWB PK-261* 1 65 SWITCH 1
20 CASE PRINTER 1 66 ANTENNA 1
21 E ARTH CLAMP 2 67 STICKER 'SEAL' 1
22 VIBRATOR ASSEMBLY 2 68 PWB PK-265* 1
23 EARTH CLAMP 1 69 BRACKET CONNECTOR ASSEMBLY 1
24 FRAME PRINTER UPPER 1 70 BRACKET LEVEL 1
25 FRAME PRINTER 1 71 LEVEL UNIT 1
26 HOLDER COVER 1 72 FRAME LEVEL 1
27 BRACKET COVER 1 73 ACCESSROY PCB SUPPORT 4
28 PANEL COVER 2 74 PWB P-999B 1
29 CASE CONTROL REAR 1 75 CASE AD BOARD 1
30 PANEL BUTTON 1 76 SCREW 'SEAL' HEXA 1
31 BUSH TORQUE 2 77 SCREW 'SEAL' HEXA 1
32 BRACKET CONTROL 1 78 HARNESS S2 24V DC 1
33 POLE STAND 1 79 COVER SIDE 1
34 BRACKET POLE STAND 1 80 BLOCK B HINGE SIDE COVER 1
35 PLATE B BRACKET POLE 1 81 HARNESS S2 FRONT LCD
(
EV
)
1
36 FOOT LEVEL 5 82 HARNESS S2 REAR LCD 1
37 PLATTER ASS 1 83 HARNESS 'C2' A/D 1
38 GUIDE PLATE 1 84 FERRITE CORE 1
39 STICKER VOID 2 85 HARNESS 'C2' POWER ASS'Y 1
40 NAME PLATE SPEC 1 86 GASKET 20mm 1
41 LEVEL LENS 1 87 STICKER LOCATION OUTPUT 1
42 CAP 4 88 FERRITE CORE 2
43 CASE MAIN UPPER 1 89 FERRITE CORE 3
44 COVER PRINTER UPPER 1 90 FERRITE CORE 1
45 BLOCK B HINGE PLATTER 2 91 HARNESS S2 LAN 1
46 RUBBER PLATTER SUPPORT 5 92 HARNESS S2 5V POWER 1
UNI-7 Service Manual 2-9

ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
