ISHIDA UNI-7 Service Manual

Chapter 2 ASSEMBLY DRAWINGS
Parts List (Elevated Dual Printer Type)
NO. PART NAME
Q
'TY NO. PART NAME
Q
'TY
1 CASE FRONT POLE DISPLAY 1 50 PWB PK-260* 1
2 LCD 1 51 BASE 1
3 BRACKET LCD 2 52 PLATE B RS232C 1
4 ACCESSROY PCB SUPPORT 4 53 PLATE B MAGNETIC 1
5 PWB PK-263* 1 54 HARNESS 'C2' POWER ASSEMBLY 1
6 CASE REAR POLE DISPLAY 1 55 COVER FRONT ELEVATE 1
7 HINGE R 2 56 BRACKET TORQUE HINGE 1
8 COVER JOINT REAR 1 57 E ARTH CLAMP 2
9 SHEET DISPLAY PANEL 1 58 POWER SUPPLY 1
10 SHEET KEY BOARD 1 59 BRACKET POWER 1
11 KEY BOARD MEMBRANE 1 60 CASE REAR POLE 1
12 CASE FRONT CONTROL 1 61 COVER BRACKET CONNECTOR 1
13 LCD TOUCH 1 62 COVER SWITCH 1
14 SHEET DOUBLE TAPE 1 63 STICKER LOCATION OUTPIT 1
15 GASKET 115mm 1 64 STICKER 'SEAL' 1
16 PWB PK-261* 1 65 ANTENNA 1
17 VIBRATOR ASSEMBLY 2 66 FERRITE CORE 1
18 PWB PK-268* 1 67 PWB PK-265* 1
19 FRAME PRINTER UPPER 1 68 GASKET 20mm 1
20 FRAME PRINTER 1 69 BRACKET CONNECTOR ASSEMBLY 1
21 PWB PK-269* 1 70 LEVEL LENS 1
22 BRACKET PRINTER UNIT 1 71 FRAME LEVEL 1
23 PRINTER MODULE ASSEMBLY 1 72 LEVEL UNIT 1
24 PANEL COVER 1 73 BRACKET LEVEL 1
25 BUSH TORQUE 2 74 CASE AD BOARD 1
26 CASE CONTROL REAR 1 75 ACCESSROY PCB SUPPORT 4
27 BUTTON PRINTER 1 76 PWB P-999* 1
28 BRACKET CONTROL 1 77 EARTH CLAMP 1
29 POLE STAND 1 78 SCREW 'SEAL' HEXA 1
30 BRACKET POLE STAND 1 79 SCREW 'SEAL' HEXA 1
31 PLATE B BRACKET POLE 1 80 COVER SIDE 1
32 FOOT LEVEL 5 81 BLOCK B HINGE SIDE COVER 1
33 CASE PRINTER 1 82 HARNESS S2 HEAD 1
34 COLLAR SPACER 4 83 HARNESS C4 SWITCH ASSEMBLY 1
35 GUIDE PLATE 1 84 HARNESS S2 FRONT LCD 1
36 PLATTER ASSEMBLY 1 85 HARNESS S2 REAR LCD 1
37 CAP 4 86 HARNESS 'C2' A/D 1
38 PCB SUPPORT 1 87 HARNESS S2 24V DC 1
39 STICKER VOID 2 88 HARNESS 'C2' USB 1
40 NAME PLATE SPEC 1 89 LCD SHEET 1
41 CASE MAIN UPPER 1 90 SHEET KEY BOARD-PL U 1
42 COVER PRINTER UPPER 1 91 FRRITE CORE 4
43 BLOCK B HINGE PLATTER 2 92 FRRITE CORE 3
44 RUBBER PLATTER SUPPORT 5 93 FRRITE CORE 1
45 PLATTER SUPPORT 1 94 HARNESS 'S 2' 24V DC 1
46 BRACKET PLATTER SUPPORT 1 95 INSULATION SHEET 1
47 LOADCELL 1 96 HARNESS S2 LAN 1
48 BRACKET LOADCELL 1 97 HARNESS S2 5V POWER 1
49 COVER HARNESS 1
UNI-7 Service Manual 2-11

ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
