Chapter 4 ELECTRICAL SIGNALS
XJ18
No. Signal Name Direction Opposite Side
1 Unused -
2 DC+24V for drawer -
3 GND -
4 Unused -
Cash drawer 2
XJ20
No. Signal Name Direction Opposite Side
1 Unused -
2 DC+24V for drawer -
3 GND -
4 Unused -
Cash drawer 1
XJ21
No. Signal Name Direction Opposite Side
1 Cassette 0 LED -
2 Cassette 0 SENS_IN ←
3 Cassette 1 LED -
4 Cassette 1 SENS_IN ←
5 Cassette 2 LED -
6 Cassette 2 SENS_IN ←
7 Cassette 3 LED -
8 Cassette 3 SENS_IN ←
9 GND -
Cassette sensor
XJ22
No. Signal Name Direction Opposite Side
1,2,3 DC+24V main power supply -
4,5,6 GND -
Switching power
supply
XJ23
No. Signal Name Direction Opposite Side
1,2 DC+24V -
3,4 GND -
Unused
UNI-7 Service Manual 4-5
