Chapter 4 ELECTRICAL SIGNALS

XJ5

No. Signal Name Direction Opposite Side

D_Vbus -

2 U_Vbus -

3 D_D- ←→

4 U_D- ←→

5 D_D+ ←→

6 U_D+ ←→

7 D_GND -

8 U_GND -

9 D_GND -

10 U_GND -

PK-260 XJ25

XJ6

No. Signal Name Direction Opposite Side

D_Vbus (Port4) -

2 D_Vbus (Port3) -

3 D_D- (Port4) ←→

4 D_D- (Port3) ←→

5 D_D+ (Port4) ←→

6 D_D+ (Port3) ←→

7 D_GND (Port4) -

8 D_GND (Port3) -

9 Key -

10 D_GND (Port3) -

Unused

XJ1

No. Signal Name Direction Opposite Side

1 SG -

2 DC+5V -

3,4,5,6,7,8 FROM write signal ←→

Unused

4-14 UNI-7 Service Manual

Other manuals for ISHIDA UNI-7

Questions and Answers:

Need help?

Do you have a question about the ISHIDA UNI-7 and is the answer not in the manual?

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
