ISHIDA UNI-7 Service Manual

TABLE OF CONTENTS
PRECAUTIONS WHEN USING CLEANING FLUIDS
Use a soft cloth and a neutral detergent to clean the machine.
Do not use thinner, benzene, etc. Doing so may damage the original safety functions.
For some parts, use cleaning fluid (isopropyl alcohol).
 Do not use cleaning fluid near fire as the fluid is flammable.
 Do not use cleaning fluid in a poorly ventilated area. Always provide adequate
ventilation when cleaning.
Take the following actions in the event of an accident:
If the fluid gets in your eye
 Immediately wash your eye(s) with water for at least 15 minutes, and consult your doctor.
 If you wear contact lenses, remove and wash them.
If the fluid comes into contact with your skin
 Immediately rinse the area of contact with water, and then wash with soap.
 If you notice any skin abnormalities at the area of contact, or if any pain persists, consult
your doctor.
If the fumes of the fluid are inhaled
 Immediately move the victim to an area where fresh air is available, and have the victim
lie down and keep warm.
 If breathing becomes difficult or stops, provide artificial respiration and seek medical
attention immediately.
If the fluid is swallowed
 Do not try to induce vomiting.
 Do not give the victim anything to drink, and do not rinse the mouth.
 If vomiting occurs naturally, have the victim lean forward to reduce risk of aspiration.
 Keep the victim warm and seek medical attention.
UNI-7 Service Manual v

ISHIDA UNI-7 Specifications

General

Use conditions	Temperature: -5 to 35°C Humidity: 30 to 85%, Non condensing.
Power supply:	AC100 – 240V, 50 / 60Hz
Power consumption	1.0A/0.5A
Weighing capacity Scale interval	15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb
Weighting accuracy	1/3000
Printing method	Direct thermal method
Printing speed	100mm/second, 120mm/second Note: The printing speed may vary according to label conditions.
Printing effective size	56mm
Label size	Label width: 30mm to 60mm Label length: 20mm to 150mm
Operator/Customer display	7.0 inch color liquid crystal with back light, 480 X 234dots
Thermal head	2 inches (448dots) and 8 dots/mm
Number of label cassettes	7 cassettes
Program store medium	Flash ROM (32M bytes)
Input/Output	LAN 1 channel USB 1 channel CF 1 channel Drawer 2 channels
