USINGTHEMACHINE
99
MUX20JP021602
BoomLiftModels X20JPLUS
STABILISATIONPROCEDURE
Beforemovingthestabilisersmakesurethat:
•Allinstructionsprovidedinthischapterhavebeencompliedwith
•Thegroundwherethemachineisstabilisediscompactandcansupportthe
weightofthemachineandthemaximumpossiblereactionforceononestabiliser;
•therearenoobstaclesonthestab
ilisationareaandinthetrajectoryofeachin‐
dividualstabiliser;
•themachineiscompletelyclosedand aligned,inthestabilisationposition.
• Stabilisationcanbecarriedoutfromthecontrolpositioninthebasketoron
theground.Ifperformingtheoperationfromtheground,makesurethereiscom‐
pletevisibilityofthetrajectoryofeachindi
vidualstabiliserbeforemovingitand
check that at the end of the stabilisation procedure the distance between the
Alwayskeepadistancefromembankmentsorditchesthatisequivalenttothe
depthofsuchandobservetherequiredsafetydistancefrompowerlines.
Avoidanycontactwithobjectsorpersonswhenloweringthestabiliser
s.
Whenworkingtheloadononeindividualstabilisercanincreasegreatlyduetothe
shiftingofweight,especiallyifextensionand/orrotationoperationsareperformed.
THIS MUST ALSO BE CONSIDERED WHEN EXAMINING THE
GROUND.
Thecompleteclosureandalignmentis
displayedbythe arrowsonthemachi‐
neandthedi
splayofthe  iconinposi‐
tion 6 on the remote controlʺFig.
42 Aerial part closed and
aligned(p. 57)ʺ.
Fig.91 Arrowsfeedbackalignment
