100
BoomLiftModels X20JPLUS
USINGTHEMACHINE
MUX20JP021602
groundandthelowerlimitofthebasketaccessladderislessthan40cm.Ifthisis
notthecase,movetheladdertothegroundandcarryoutthestabilisationproce‐
durefromthebasket.
•Select the motor speed as required and check the selection on the display.
Alwaysperformstabilisationatsl
owspeed.
•Pressand holdtheautomaticstabilisationbutton7ʺPushbuttons(p. 61)ʺ.If
themovementsareselectedwiththemachinenotcompletelyclosedandaligned,
an
•errormessagewillbeshownonthedisplay.
• Stabilisation will be completed when the machine is in horizontal position
withtoleranceof1°andli
ftedatleast5cmfromtheground.Correctstabilisation
will be confirmed by the icon in position 5 on the displayʺFig. 39 Stabilized
machine(p. 56)ʺ.Alwayscheckthespiritlevelandmakesuretheslopeisactually
lessthan1°.
MANUALSTABILISERCONTROL
Themanualcontrolofthestabilisersmustnotbeusedtos
tabilisethemachinebut
onlytocorrectitsinclinationintheeventofstabilisationindifficultconditions.It
canalsobeusedtolowerorliftthestabilisersindividuallyinordertoincreasethe
stabilityofthemachine,ifitisnecessarytotransitareaswithobstaclesorsteep
slopes.
Fig.92 Err
orclosemachine
