BoomLiftModels X20JPLUS
USINGTHEMACHINE
MUX20JP021602
OVERLOADALARM
Ifduringthebasketloadingphasesthemaxallowableloadisexceededbasedon
thepositionoftheJIBboom,allmovementsoftheaerialpartwillbedisabledand
anerrormessagewillbeshownonthedisplay,firstontheentirescreenandthen
inposition5.
Thealarmwillonlyberese
twhentheoverloadisremoved.Normalmachineope‐
rationcanberesumedonlythen.
BASKETLIFTINGALARM
Ifwhenusingthe machineat aheight, forwhateverreason,thebasketislifted
fromitspositionontheloadsensor,analarmpreventsallmovementsofthema‐
chineandthedi
splayontheremotecontrolshowsanerrormessage.
Thealarmisresetonlywhenthebasketisfittedbackontheloadsensor.
Fig.101 Overloadalarm Fig.102 Overload
Fig.103 Basketliftingalarm
