JLG X20JPLUS - Page 82

80
BoomLiftModels X20JPLUS
EMERGENCYDEVICE
MUX20JP021602
Fig.80 Decalsnearthecontrolground1 Fig.81 Decalsnearthecontrolground2
Ref. Description Drive/Motion
1 Rearleftstabilisercon‐
trol
Movingleverdownwards:
stabilizerdown
Movingleverupwards:
stabilizerup
2 Frontleftstabilisercon‐
trol
Movingleverdownwards:
stabilizerdown
Movingleverupwards:
stabilizerup
3 Lefttrackcontrol Movingleverupwards:
moveslefttrackforward
Movingleverdownwards:
moveslefttrackbackward
4 Trackextension Movingleverupwards:
extendstrack
Movingleverdownwards:
narrowstrack
5 Rightt
rackcontrol Movingleverupwards:
movesrighttrackforward
Movingleverdownwards:
movesrighttrackbackward
6 Frontrightstabiliser
control
Movingleverdownwards:
stabilizerdown
Movingleverupwards:
stabilizerup
