EMERGENCYDEVICE
81
MUX20JP021602
BoomLiftModels X20JPLUS
Atthehydraulicdistributorstherearealsothemainproportionalvalvesground
part.Thevalvesisequippedwithamanualcontrolforthedriveincaseoffailure
7 Rearrightstabilisercon‐
trol
Movingleverdownwards:
stabilizerdown
Movingleverupwards:
stabilizerup
Neveroperatethemanualcontroloftheproportionalvalvedu
ring
normaloperationofthemachine.
Ref. Description Drive/Motion
