BFH 2000
161
Эксплуатация АВТОМАТИЧЕСКИЙ РЕЖИМ
OPTIMA FULL DIAGNOSTIC
Operation - AUTOMATIC
"OPTIMA FULL DIAGNOSTIC"

 (Рис. 7-88) "INTERNAL SIDEWALL
PLOT" :
 F2  "INTERNAL SIDEWALL" (5, Рис. 7-87).
Рис. 7-88
     
 (E) .
  ,  
.
   
   
   .  
   
    
  
 .
     (F)
    
 (I).
Примечание:
  (I) ,
  (Е)  
 .  
    
.

(Fig. 7-90) "EXTERNAL SIDEWALL
PLOT" :
F2  "EXTERNAL SIDEWALL" (6, Рис. 7-89).
Рис. 7-90
     
 (G) .
     (H)
    
 (I)  (G).
Примечание:
(I)   
 .
ВНИМАНИЕ:
Для колес с внешним диаметром более 30
дюймов могут потребоваться специальные
адаптеры, чтобы правильно определить
параметры колеса.
To display the
"INTERNAL SIDEWALL PLOT"
screen select:
F2 Menu, "INTERNAL SIDEWALL" item (5, Fig. 7-87),
displays the screen with the analysis of the internal
sidewall (Fig. 7-88).
Fig. 7-88
The top shows the flat internal tyre sidewall view (E) for a
section of the circumference.
Rotate manually to scroll and display the sidewall of
the entire circumference.
The colour provides information on the uniformity of the
internal sidewall of the tyre and rim, including part of the
rim. A uniform colour indicates a uniform sidewall, whilst
changes in colour indicate structural deformations and, if
slight, they indicate lack of linearity.
On the bottom there is the graph (F), of the section of
tread examined. The line reproduces the structure of the
tyre sidewall and of part of the rim, in the exact point
indicated by the angular position index (I) along the
circumference.
Note:
The angular position index (I) is fixed on the trace,
whilst the wheel display (E) moves as the wheel is
rotated. The index corresponds to the 12 ock
physical position on the wheel.
To display the
"EXTERNAL SIDEWALL PLOT"
screen select:
F2 Menu, "EXTERNAL SIDEWALL" item (6, Fig. 7-89),
displays the screen with the analysis of the external
sidewall (Fig. 7-90).
Fig. 7-90
The flat external tyre sidewall view (G) is shown for a
specific section of the circumference.
On the bottom there is the graph (H) with the wheel
sidewall profile in the exact position indicated by the index
(I) in the view (G).
Note:
The index (I) corresponds to the 12 k physical
position on the wheel.
ATTENTION:
Wheels with an external diameter greater than 30
inches, may require the use of specific adaptors to
read the wheel sidewall correctly.
