The X9503 2.4 offers a sophisticated program with easy
preset trim positions for the elevator, flaps, flaperons
(and even the aileron and rudder if you choose). The
system can remain active in flight allowing you to fine-
trim presets in each flight mode or can be locked in so
they cannot be altered in flight. Flight mode presets are
automatically selected via the flight mode switch and are
adjusted with the digital elevator trim, the digital flap trim
and the digital auxiliary trim (flaperon). While the presets
are adjusted via the digital trims, their positions are
recorded in the servo monitor.
To access the servo monitor, in FUNC.LIST highlight
MONITOR. Press the Selector to access the Monitor
menu then press the Selector again to access the camber
digital preset screen. To adjust the presets, move the
flight mode switch to the land mode (down) position.
Adjust the preset positions via the flap trim, auxiliary
trim and elevator trim on the transmitter. The values will
will display in the screen and then will be memorized for
that flight mode. If you want these preset values to be
fixed (not active in flight) once the values are established,
return to the Trim Step screen in the system mode and
reduce the value of the desired channel to 0. The preset
values for all flight modes will be stored and no longer
accessible with the digital trims.
In
FUNC.LIST, highlight D/R & EXP. Press the Selector
to access the Dual Rate and Exponential menu. Highlight
the channel (aile, elev or rudd) then press the Selector
to select the channel you wish to adjust the dual and expo
rates for. Rotate to select then press the Selector to store
the desired channel.
Note that three D/R and EXPO positions (values) are
available (Pos0, 1 and 2).
Under AUTO on the right of the screen, highlight LAND
and press the Selector. Select POS2 as the active
position for land mode by rotating the Selector and
pressing the Selector when
POS2 is highlighted. This
automatically accesses dual rate and expo values that
are programmed into position 2 whenever land mode is
selected. Now rotate the Selector to
POS2 and depress
to highlight the D/R values. Rotate the Selector to
change these values. Displace the aileron stick right or
left to independently adjust the dual rate in each direction.
Depress the Selector to store the desired D/R values.
Rotate the Selector to the
EXP Pos2 values and adjust
these values in the same manner. Press the Selector to
store the desired value.
Now go back to channel and repeat for the two remaining
channels. Press the LIST button to return to the Function
Mode screen.
