JR X9503 Transmitter
Section 2: Transmitter and Receiver Specifications
Section 1: Using the Manual
G-8
G-9
JR’s X9503 2.4 offers airplane, helicopter and sailplane
pilots sophisticated programming that JR’s 9303 is
famous for with the added benefits of a backlight screen,
50-model memory, and new throttle timer start for
aircraft and helicopter model types plus fully integrated
Spektrum 2.4GHz DSM
®
radio link technology. DSM
(Digital Spektrum Modulation) technology offers a far
superior RF link than narrow band 72MHz FM and PCM
systems, providing a higher level of confidence and
safety. Now with even the most sophisticated models
up to 9 channels, you’ll no longer have to wait for an
open frequency, worry about someone unintentionally
powering up on the same frequency, or have to plan a
frequency-based flight matrix for competition. And for
response-critical aircraft like 3D helicopters and airplanes,
latency (the time it takes for a stick input to translate to a
servo output) is significantly reduced providing a more
responsive precise connection to your model.
Features
•Fullyintegrated2.4GHzSpektrumRFlink
•Sophisticatedthree-model-typeprogramming:Airplane,Helicopter,Sailplane
•PatentedDuaLink
®
technology
•ModelMatch
™
•ServoSync
™
•RollingSelectorinput
•Digital3+1trims
•50-modelmemory
•Backlightscreen
Specifications
•Modelnumber—Airplane/Sailplane(JRP2930),Helicopter(JRP2935)
•Numberofchannels—9
•Modulationtype—DirectSequenceSpreadSpectrumDSM2/DSM1protocol
•Band—2.400to2.483GHz
•Spectralcapacity—40simultaneoussystems
•Transmittercurrent—180mA/DSM2280mA/DSM1
•Resolution—2048withR921receiver
In the front of this manual you will find common
transmitter features and specifications plus information
on the included components and accessories. Guidelines
for receiver and servo installation are also included. In
each section of this manual (Air, Heli and Sailplane) are
instructions for adjusting model-specific programming
and functions. An explanation of the purpose of each
programming function is provided, followed by an
illustrationofitscorrespondingLCDdisplayand
instructions on how to access and adjust the function.
A blank data sheet has been included at the end of each
section, as well as on the JR web site. Once all data has
been input for a particular model, you should record
these values and settings on a copy of the data sheet, so
in the rare event of a loss of memory, these settings are
available.
Note:ThemanualfortheX95032.4manualisposted
online at www.horizonhobby.com in the support section or
it can be ordered from your local hobby dealer or directly
from Horizon Hobby.
Step #24 Dual Rate and Exponential ......................................................................................................... S-56
Step #25 Elevator-to-Flap Mix
.................................................................................................................... S-57
Step #26 Aileron-to-Flap .............................................................................................................................. S-58
Step #27 Aileron Differential ....................................................................................................................... S-58
Flap Rate ...................................................................................................................................................... S-59
Flaperon Mix ............................................................................................................................................... S-59
Step #28 Flap Rate, Camber Mix and Camber Adjust ........................................................................... S-59
Step #29 Flap Rate, Camber Mix and Camber Adjust (continued) .................................................... S-60
Flaperon Mix Delay .................................................................................................................................... S-60
Setting Up Land Mode .............................................................................................................................. S-61
Step #30 Aileron-to-Rudder Mix .............................................................................................................. S-61
Step #31 Land Pre-sets ................................................................................................................................. S-62
Step #32 Dual Rate and Exponential ......................................................................................................... S-63
Step #33 Elevator-to-Flap Mix .................................................................................................................... S-64
Step #34 Aileron-to-Flap .............................................................................................................................. S-64
Step #35 Aileron Differential ....................................................................................................................... S-64
Flaperon Mix ............................................................................................................................................... S-65
Flaperon Mix ............................................................................................................................................... S-65
Step #36 Flap Rate, Camber Mix and Camber Adjust ........................................................................... S-65
Step #37 Flap Rate, Camber Mix and Camber Adjust (continued) .................................................... S-66
Step #38 Aileron-to-Rudder Mix .............................................................................................................. S-66
Flaperon Mix Delay .................................................................................................................................... S-66
Setup Sheet (Sailplane) .................................................................................................................................. S-67
Servo Precautions .......................................................................................................................................... W-1
General Notes ................................................................................................................................................ W-1
Federal Aviation Administration .................................................................................................................. W- 2
1. Purpose .................................................................................................................................................... W-2
2. Background .............................................................................................................................................. W-2
3. Operating Standards ............................................................................................................................. W- 2
Warning ........................................................................................................................................................ W- 3
Warranty Period ........................................................................................................................................ W- 3
Limited Warranty ....................................................................................................................................... W- 3
Damage Limits ............................................................................................................................................ W- 3
Safety Precautions ...................................................................................................................................... W- 3
Questions, Assistance, and Repairs ........................................................................................................ W-3
Warranty and Service Information ............................................................................................................ W-3
Warranty and Service Information ............................................................................................................ W-4
Inspection or Repairs ................................................................................................................................ W- 4
Warranty Inspection and Repairs ........................................................................................................... W-4
Non-Warranty Repairs ............................................................................................................................. W-4
Safety, Precautions, and Warnings ........................................................................................................... W-4
Instructions for Disposal of WEEE by Users in the European Union ............................................ W-5
FCC Information ........................................................................................................................................ W- 5
