D/R & EXP – DUAL RATE AND EXPONENTIAL REV.SW – SERVO REVERSING
S-18
S-19
Three dual and exponential rates are available. You can
select them via flight modes or selected switches. You
can independently adjust Dual and Expo rates in each
direction by moving the appropriate stick in the desired
direction.
1. Highlight and select D/R & EXP in the FUNC.LIST
to obtain the display. If you previously selected Flight
Modes in the Devic. SEL function and set D/R to FM,
3 sets of values will display for each channel - Aileron,
Elevator and Rudder.
2. Use the Selector to change between Aileron,
Elevator and Rudder. Then use it to set dual rate and
exponential values.
The servo reverse screen allows you to select the direction
of each servo.
1. Highlight and select REV.SW in the FUNC.LIST.
2. Use the Selector to highlight and select those
channels that need to be reversed. Pressing
the Selector toggles the channel between
Normal and Reverse.
