JR X9503 2.4 User Manual

JR R921 Receiver
Charger Specifications
Section 3: Component Specifications
G-10
G-11
TheR921receivercombinestwointernalwithoneor
two (optional) remote receivers, offering superior path
diversity.Theradiosystemsimultaneouslytransmits
on two frequencies, creating up to four RF paths on two
different2.4GHzchannels.Thismulti-pathredundancy,
plus the fact that each of the up to 4 receivers are located
in different locations throughout the aircraft exposes each
to a different RF environment creating a superior RF
linkinallconditions.TheJRR921allowstheuse
ofanoptionalFlightLogDataRecorder(JRPA145)to
beused.TheFlightLogplugsintothedataportand
provides quality of RF link data of the previous flight
allowing the confirmation of the operational performance
of the systems.
Features
•9channels
•2internalreceivers
•1or2(optional)remotereceiver(s)
•PatentedMultiLinktechnology
•Twotypesoffail-safe—SmartSafe
™
and Preprogrammed fail-safe
•FlightLogcompatible
Specifications
•Numberofchannels—9
•Modulation—DSM2
•Band—2.400to2.4835GHz
•Dimensions(WxLxH)—1.23x1.94x.56in
•Weight—Main15g/.6ozRemote3g/.2ozeach
•Current—70mA
•Voltagerange—3.5to9.6V
Note:TheX95032.4isalsocompatiblewithallcurrentJRandSpektrumDSMaircraftreceiversincluding:
AR5005-channel,AR6000,AR6100/E,AR6110/E,AR6300,AR6400/L6-channelparkflyer
AR6200,AR62506-channelfullrange
AR7000,AR7100,AR76007-channelfullrange
AR9000,AR9100,AR93009-channelfullrange
R9229-channelfullrangeandR1221,R122212-channelfullrange
Important:WhenusingtheX95032.4withparkflyerreceivers(theAR6000,AR6100/E,AR6110/E,AR6300and
AR6400),it’simperativethatthesereceiversonlybeflowninparkflyer-typeaircraft(smallelectricairplanesormini
and micro helicopters). Flying receivers designed for parkflyers in larger aircraft could cause loss of control.
Model Number AD35M05
InputVoltage AC120V,60Hz
OutputCurrent 11.6VTransmitter/110mAh,5.8VReceiver/110mAh
ChargingTime 15hours
