2.4.1 Battery discharge monitor with bar display
Z
When a battery is discharged to the permissible level (residual capacity), the battery
symbol in the driver's display is empty and flashing. An indicator appears in the
driver's display. The load handler can no longer be lifted.
Battery symbol Meaning
Permanently lit
Battery is charged.
– The more bars the battery discharge indicator shows,
the greater the battery's residual capacity.
Flashing
Battery charge recommended.
– Depending on the battery type, the battery discharge
indicator symbol flashes when there are one or two
remaining bars.
Battery charge required (charge is below residual
capacity level).
– The battery discharge indicator symbols does not
show any bars.
– The load handler can no longer be lifted. The lift
function is disabled by the controller.
"Raising" is only released when the connected battery:
– is at least 40 % charged (two bars) for a wet-cell battery.
– is at least 50 % charged (three bars) for a gel battery.
105
04.19 en-GB
