4.4 Weights
4.4.1 Basis truck weight including support arm and the lift masts including fork
carriage
15
43
18
19
44
Basis truck weight including support arm and counterweights (without battery)
Z
The weight of the basic truck (43) including support frame (18) und
counterweights (44)can be found in the following table. Depending on the battery
type used, counterweights (44) must be fitted in the battery compartment in order to
guarantee the stability of the truck (see page 73). Battery equipment may only be
replaced with the agreement of the manufacturer.
Truck model
Dimension
"Y"
Counterweights
Basis truck weight
including attachment and
counterweights
EFX 410
0 mm 0 kg 3145 kg
90 mm 152 kg 3297 kg
180 mm 304 kg 3449 kg
EFX 413
0 mm 0 kg 3445 kg
90 mm 152 kg 3597 kg
180 mm 304 kg 3749 kg
35
04.19 en-GB
