4.3 Mast versions
4.3.1 Standard mast version with telescopic mast (ZT)
Telescopic mast design (ZT)
The telescopic mast (ZT) consists of the following components:
– Outer mast.
The outer mast is rigidly connected to the basic truck.
– Inner mast.
The inner mast runs in the outer mast.
– Fork carriage with forks.
The fork carriage runs in the inner mast.
Operating principle of the telescopic mast (ZT)
When operating the hydraulic "lift" function, the inner mast is lifted by two outer
hydraulic cylinders (see page 171). The fork carriage is raised at the same time by
chains.
Z
For a description of hydraulic "lift" function, see page 171.
WARNING!
Risk of collision caused by the lift mast due to the changed mast height (h
1
)
The dimension "mast height lowered“ (h
1
) increases as soon as the fork carriage is
raised. The operator must take this changed mast height into account when
operating the truck (e. g. when driving through doorways, when the ceiling is low,
etc.).
u
When operating the truck, ensure that the lift mast does not collide with obstacles.
Description EFX 410 EFX 413
h
1
Mast height lowered 2305 – 3875 2305 – 3875 mm
h
2
Free lift 66 66 mm
h
3
Lift 3000 – 6000 3000 – 6000 mm
h
4
Mast height extended 3772 – 6842 3772 – 6842 mm
h
6
Height of overhead guard
2277
1)
2277
1)
mm
h
7
Seat height 1205 1205 mm
1 with a strobe light this dimension increases to approx. 2377 mm
33
04.19 en-GB
