6.5
Lift cutout override (o)
Z
If local conditions require, an automatic lift cutout can be installed to be activated
from a given lift height. The automatic lift cutout prevents the Main Lift from raising.
The driver's display shows the "Lift cutout override" symbol (161).
WARNING!
An extended mast can cause accidents
The lift cutout is an auxiliary function designed to support the operator which
however does not release him from his responsibility to stop hydraulic operations
e.g. when confronted with an obstacle.
u
When the lift cutout has been de-activated the truck must be operated with extra
care in order to detect obstacles when the mast is extended.
u
Stop lifting before you reach the obstacle.
Z
Lift cutout only becomes effective after referencing has been carried out (see
page 147). When referencing has been completed, the height actual value is shown
in the driver's display.
217
04.19 en-GB
