5.4 Attachment capacity plate
The attachment capacity plate indicates the industrial truck's capacity Q (kg) in
conjunction with the attachment fitted. The serial number on the capacity plate must
match the data plate of the attachment, as the specific capacity for each truck is
specified by the manufacturer. The capacity is shown in the same way as the truck’s
capacity and is to be determined in the same manner.(see page 46).
Z
For loads with a load centre distance greater than 600 mm the capacities are
reduced depending on h
3
. Refer to the data on the capacity plate of the attachment.
5.5 Jack contact points
The "Jack contact point" decal (62) indicates where the truck may be lifted and
jacked up (see page 317)
47
04.19 en-GB
