Jungheinrich EFX 413 - Rack Height Select (o)

8.6
Rack Height Select (o)
To lift or deposit loads in pre-selected storage locations, the truck must be adapted
to the warehouse setup.
Z
The manufacturer's customer service department is specially trained to carry out
these operations.
In addition to the current lift height, the following symbols are shown in the
driver's display:
Symbol
Function
Attachment
– Attachment in home position without load
– Attachment in home position with load
– Lifting or lowering an attachment without load
– Lifting or lowering an attachment with load
– Traversing an attachment to the left or right without load
– Traversing an attachment to the left or right with load
– Zone selection
– Area selection
Z
A load sensor between the forks detects whether there is a load on the forks.
265
04.19 en-GB
