Mast weight including fork carriage
Z
The weight of the mast (15) including the fork carriage (19) can be calculated using
the formula given below. The data required, for example the net weight (overall
weight) of the truck without battery, are to be found on the data plate, see page 45.
A Net weight of the industrial truck without battery
B Mast weight including fork carriage
Formula for the EFX 410:
B = A - 3145 kg
Formula for the EFX 413:
B = A - 3445 kg
Example:
Required information:
(see truck data plate)
– Type of industrial truck = EFX 413
– Net weight of the industrial truck without battery = 4350 kg
Formula:
B = A - 3445 kg = 4350 kg - 3445 kg = 905 kg
Z
The mast weight including fork carriage is 905 kg.
36
04.19 en-GB
