NOTICE
Note the safety clearances between the truck and rack
Refer to the following table for the safety clearances required by the manufacturer
depending on the type of guidance system and the lift height (h
3
).
Truck guidance in the narrow
aisle
Lift height (h
3
)
Safety clearance
Wire-guided truck
depending on the lift
height (h
3
)
125 mm
Rail-guided truck
to 4000 mm 90 mm
to 6000 mm 100 mm
from 6000 mm 125 mm
Z
The safety distance may, however, increase if special attachments are fitted.
Travelling in narrow aisles with rail-guided trucks
Requirements
– Narrow aisles must be equipped with guide rails (166).
– Prepare the truck for operation, see page 138 or see page 139.
160
04.19 en-GB
