Jungheinrich EFX 413 User Manual

4.15.2
Automatic traverse/rotate operation (o)
Z
In automatic traverse/rotate operation the
fork carriage rotates as the attachment is
moving.
Requirements
– Prepare the truck for operation, see
page 138 or see page 139.
Procedure
• Do not press the dead man's switch (20).
• Press the key (104) under the
"synchronised rotate menu change"
symbol (173).
The display changes from the menu item
“synchronised rotation menu
change” (173) to "synchronised fork
rotation to the right " (175) or
"synchronised fork rotation to the
left" (174).
Z
The rotary and traverse speeds are
preset. Automatic traverse/rotate
operation can be cancelled by releasing
the key (104). The attachment must then
be moved manually to the home position.
• Synchronised fork carriage rotation to the
right and attachment traverse to the left:
• Press and hold down the key (104)
under the "synchronised fork rotation to
the right " symbol (175) until the home
position has been reached.
• Synchronised fork carriage rotation to the
left and attachment traverse to the right:
• Press and hold down the key (104)
under the "synchronised fork rotation to
the left" symbol (174) until the home
position has been reached.
The attachment is located at the right or left
mechanical limit position of the swivel
traverse frame and the forks are rotated
through 180°.
113
20
104
175
174
113
20
104
173
185
04.19 en-GB
