Load handler emergency lowering
Requirements
– Load handler is not in the rack.
Tools and Material Required
– Allen key (key width 6) to undo the lowering valve (181).
Procedure
Z
If necessary, the load handler can be lowered from below by the operator or an
assistant.
• Switch off the truck; to do this:
• Turn the key in the key switch as far to the left as it will go (8).
•
Press the red button of the ISM access module (o) twice in a row.
• Press the emergency disconnect switch (9).
• Open the drive compartment cover (35) see page 334.
• Turn the lowering valve (181) with the Allen key (180):
• a maximum of two revolutions anticlockwise:
The load handler is lowered.
Z
The lowering speed increases the further the lowering valve (181) is opened.
• clockwise as far as it will go:
Lowering is stopped.
• Close the drive compartment cover (35), see page 334.
213
04.19 en-GB
