Travel within narrow aisle (narrow aisle without end of aisle safety device)
Truck travel function Function of the Floor-Spot
• Guided truck travels in drive direction
• Floor-Spot (247) is switched on.
• Floor-Spot (246) is switched off.
• Guided truck travels in load direction
• Floor-Spot (246) is switched on.
• Floor-Spot (247) is switched off.
Narrow aisle exit (leaving the narrow aisle)
Truck travel function Function of the Floor-Spot
• Guided truck passes over the end of aisle
safety device in the drive direction
• Floor-Spot (247) is switched on.
• Floor-Spot (246) is switched off.
• Guided truck passes over the end of aisle
safety device in the load direction
• Floor-Spot (246) is switched on.
• Floor-Spot (247) is switched off.
Narrow aisle exit (guided travel outside of the narrow aisle)
Truck travel function Function of the Floor-Spot
• Guided truck exits the narrow aisle in the
drive direction
• Floor-Spot (247) is switched on.
• Floor-Spot (246) is switched off.
• Guided truck exits the narrow aisle in the
load direction
• Floor-Spot (246) is switched on.
• Floor-Spot (247) is switched off.
316
04.19 en-GB
