Description EFX 410 EFX 413
D Load centre distance 600 600 mm
x Load distance 168 168 mm
y Wheelbase 1577 1577 mm
z
Distance from centre of drive wheel to truck
perimeter
270 270 mm
h
1
Mast height lowered 2805 2805 mm
h
2
Free lift 66 66 mm
h
3
Lift
4000
1)
4000
2)
mm
h
4
Mast height extended
4772 4772
mm
h
6
Height of overhead guard
2277
3)
2277
3)
mm
h
7
Seat height 1205 1205 mm
A
st
Working aisle width for pallets 1200 x 1200 1740 1740 mm
A
st3
Transfer aisle width for pallets 1200 x 1200 3482 3482 mm
Wa Turning radius 1847 1847 mm
s
Fork dimensions
40 40 mm
e 100 100 mm
l 1200 1200 mm
-- Lowest position top of fork tine (s + 25 mm) 65 65 mm
Z
The data listed in the table (performance data, dimensions and weights) are based
on a truck with the following masts.
The data (performance data, dimensions and weights) for the particular truck
supplied can be found on the data plate.
1 EFX 410 with 400 telescopic mast (ZT mast)
2 EFX 413 with 400 telescopic mast (ZT mast)
3 with a strobe light this dimension increases to approx. 2377 mm
4 with transponder readers (RFID readers) this dimension is reduced to approx. 45
mm
30
04.19 en-GB
