Figure 23: DC Power Supply in ACX5048 Routers
3—1— Ejector leverTerminal block
4—2— HandleESD grounding point
Figure 24: DC Power Supply for an ACX5096
3—1— Ejector leverTerminal block
4—2— HandleESD grounding point
NOTE: The DC power supply in the router has four terminals labeled V–, V–,
V+, and V+ (see Figure 25 on page41) forconnectingDC power source cables
labeled positive (+) and negative (–).
Copyright © 2015, Juniper Networks, Inc.40
ACX5048 and ACX5096 Universal Access Router
