Table 39: Optical Interface Support and Copper Interface Support for SFP Transceivers in

EX2300 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-1GE-SXModel number1000BASE-SX

1000 MbpsRate

LCConnector type

DualFiber count

850 nmTransmitter wavelength

–9.5 dBmMinimum launch power

–3 dBmMaximum launch power

–21 dBmMinimum receiver sensitivity

0 dBmMaximum input power

MMFFiber type

50/125

µm

50/125

µm

62.5/125

µm

62.5/125

µm

Core/Cladding size

OM2–OM1FDDIFiber grade

500

MHz/km

400

MHz/km

200

MHz/km

160

MHz/km

Modal bandwidth

550 m (1804 ft)500 m

(1640 ft)

275 m

(902 ft)

220 m

(722 ft)

Distance

Junos OS for EX Series switches, Release 15.1X53-D50 or laterSoftware required

NoSupport for Virtual Chassis

configuration
