Juniper EX3300 Series User Manual

CAUTION: Using a grounding cable with an incorrectly attached lug can
damage the switch.
Follow the procedure that applies to your switch:
•
Connecting Earth Ground to an EX2200, EX3200, or EX3300 Switch on page 84
•
Connecting Earth Ground to an EX4200 Switch on page 85
•
Connecting Earth Ground to an EX4500 Switch on page 86
•
Connecting Earth Ground to an EX6210 Switch on page 87
•
Connecting Earth Ground to an EX8208 Switch on page 89
•
Connecting Earth Ground to an EX8216 Switch on page 89
Connecting Earth Ground to an EX2200, EX3200, or EX3300 Switch
The protective earthing terminal is located on the rear of the chassis in an EX2200 switch,
EX3200 switch, and in an EX3300 switch.
An AC-powered EX Series switch chassis gets additional grounding when you plug the
power supply in the switch into a grounded AC power outlet by using an AC power cord
appropriate for your geographical location. For EX2200 switches, see AC Power Cord
Specifications for EX2200 Switches. For EX3200 switches, see AC Power Cord
Specifications for EX3200 Switches. For EX3300 switches, see “AC Power Cord
Specifications for EX3300 Switches” on page 56.
Ensure that you have the following parts and tools available:
•
Grounding cable for your switch—The grounding cable must be minimum 14 AWG
(2 mm²), minimum 90°C wire, or as permitted by the local code.
•
Grounding lug for your grounding cable—The grounding lug required is a Panduit
LCD6-14BH-L or equivalent.
•
Washers and 10-32x.25-in. screws to secure the grounding lug to the protective earthing
terminal
NOTE: Someearly models of EX3200 switchesrequire 10-24x.25-in. screws
rather than 10-32x.25-in. screws. If the Juniper Networks product number
on the label next to the protective earthing terminal is from 750-021xxx
through 750-030xxx, the switch requires 10-24x.25-in. screws.
•
Phillips (+) screwdriver, number 2
To connect earth ground to an EX2200, EX3200, or EX3300 switch:
Copyright © 2011, Juniper Networks, Inc.84
Complete Hardware Guide for EX3300 Ethernet Switches

Juniper EX3300 Series Specifications

General

Layer Support	Layer 2 and Layer 3
JUNOS OS	Yes
Ports	24 or 48 x 10/100/1000BASE-T ports
Uplink Ports	4 x 1GbE/10GbE SFP/SFP+ ports
Power Supply	AC or DC options
Stacking	Yes, up to 10 units
MAC Address Table Size	32, 000
Operating Humidity	10% to 90% non-condensing
PoE Support	Available on PoE models
Virtual Chassis	Yes, up to 10 units
Operating Temperature	32° to 104° F (0° to 40° C)
