Mounting an EX3300 Switch
You can mount the switch:
•
On two posts in a 19-in. rack or cabinet by using the mounting brackets provided with
the switch.
•
On four posts in a 19-in. rack or cabinet by using the separately orderable four-post
rack-mount kit.
•
In a position recessed 2 in. from the front of a 19-in. rack or cabinet by using the
2-in.-recess front brackets in the separately orderable four-post rack-mount kit. You
can mount the switch in this recessed position on two-post or four-post racks and
cabinets.
•
On a desk or other level surface by using rubber feet. The switch is shipped with four
rubber feet to be used to stabilize the chassis on a desk or other level surface.
•
On a wall by using the separately orderable wall-mount kit.
WARNING: When mounting an EX3300 switchchassisin a vertical position,
orient the front panel of the chassis downward to ensure proper airflow
and meet safety requirements in the event of a fire.
The holes in the mounting brackets are placed at 1 U (1.75 in. or 4.45 cm.) apart so that
the switch can be mounted in any rack or cabinet that provides holes spaced at that
distance.
Related
Documentation
Mounting an EX3300 Switch on Two Posts in a Rack or Cabinet on page 68•
• Mounting an EX3300 Switch on Four Posts in a Rack or Cabinet on page 71
• Mounting an EX3300 Switch in a Recessed Position in a Rack or Cabinet on page 74
• Mounting an EX3300 Switch on a Desk or Other Level Surface on page 74
• Mounting an EX3300 Switch on a Wall on page 75
• Connecting Earth Ground to an EX Series Switch on page 83
Mounting an EX3300 Switch on Two Posts in a Rack or Cabinet
You can mount the switch on two posts of a 19-in. rack or cabinet by using the mounting
brackets provided with the switch. (The remainder of this topic uses “rack” to mean “rack
or cabinet”.)
You can mount the switch on four posts of a four-post rack by using the mounting brackets
provided with the separately orderable four-post rack-mount kit. See “Mounting an
EX3300 Switch on Four Posts in a Rack or Cabinet” on page 71.
Copyright © 2011, Juniper Networks, Inc.68
Complete Hardware Guide for EX3300 Ethernet Switches
