Table 6 on page 18 describes the Link/Activity LED.
Table 6: Link/Activity LED on the Network Ports and Uplink Ports in EX3300 Switches
State and DescriptionColorLED
Blinking—The port and the link are active, and there is link activity.
On steadilyThe port and the link are active, but there is no link activity.
Off—The port is not active.
GreenLink/Activity
The LEDs labeled Status LED in Figure 7 on page 17 and Figure 8 on page 17 indicate the
status of one of the four port parameters—speed, administrative status, duplex mode,
and Power over Ethernet Plus (PoE+) status. From the Idle menu of the LCD, use the
Enter button on the LCD panel to toggle between the SPD,ADM, DPX, and POE, indicators.
Table 7 on page 19 describes the Status LED.
Copyright © 2011, Juniper Networks, Inc.18
Complete Hardware Guide for EX3300 Ethernet Switches
