Juniper SRX210 - HARDWARE GUIDE REV 3 - Monitoring the SRX210 Services Gateway Using Chassis Alarm

Table 42: Component LEDs on the Services Gateway (continued)
Possible Causes and
Corrective ActionsMeaningStateLED
The device is not part of the
chassis cluster setup.
OffHA LED
Normal condition. No action
is required.
The Mini-PIM is present and
detected by the device.
GreenMini-PIM LED
See “Monitoring the SRX210
Services Gateway Using
Chassis Alarm Conditions”
on page 118.
The Mini-PIM is not present
or is not detected by the
device.
Off
Normal condition. No action
is required.
The port is inactive.OffVoice Interface
LED
Normal condition. No action
is required.
The port is active and
functioning normally.
Green (Steady)
Normal condition. No action
is required.
The port is active and not
ready for data
communication.
Amber
Normal condition. No action
is required.
The port is active and data
communication is taking
place.
Green (Blinking)
Normal condition. No action
is required.
The port is initializing.
NOTE: The Voice Interface
port LED glows red (blinking)
while initializing. If there is an
error, the LED remains red;
otherwise, the LED changes
to green.
Red (blinking)
Contact the Juniper
Networks Technical
Assistance Center (JTAC).
See “Juniper Networks
Technical Assistance
Center” on page 122.
The Port has detected a
hardware initialization failure.
Red (steady)
Related
Documentation
Monitoring the SRX210 Services Gateway Chassis Using the CLI on page 113•
• Monitoring the SRX210 Services Gateway Using Chassis Alarm Conditions on page 118
• Monitoring the SRX210 Services Gateway Power System on page 119
• Using the Reset Config Button on the SRX210 Services Gateway on page 121
• Changing the Reset Config Button Behavior on the SRX210 Services Gateway on page 121
• Juniper Networks Technical Assistance Center on page 122
117Copyright © 2010, Juniper Networks, Inc.
Chapter 18: Monitoring the SRX210 Services Gateway
