NOTE: The cable tie holder provides support to hold the power cord on to
the power supply point.
The lock provides the capability to lock and secure the device to the
installation site.
Related
Documentation
SRX210 Services Gateway Specifications on page 7•
• SRX210 Services Gateway Built-In Interfaces on page 14
• SRX210 Services Gateway LEDs on page 18
• SRX210 Services Gateway Boot Devices and Dual-Root Partitioning Scheme on page 22
• SRX210 Services Gateway Cooling System on page 23
• SRX210 Services Gateway Power Supply on page 25
SRX210 Services Gateway with Integrated Convergence Services Front Panel and Back
Panel Views
This topic contains views of the front panel and back panel of the SRX210 Services
Gateway with Integrated Convergence Services. This topic includes the following sections:
•
SRX210 Services Gateway with Integrated Convergence Services Front Panel on page 12
•
SRX210 Services Gateway with Integrated Convergence Services Back Panel on page 13
SRX210 Services Gateway with Integrated Convergence Services Front Panel
Figure 5 on page 12 shows the front panel of the SRX210 Services Gateway with Integrated
Convergence Services.
Figure 5: SRX210 Services Gateway with Integrated Convergence Services
Front Panel
Table 8 on page 13 lists the front panel components of the services gateway.
NOTE: The numbers in Table 8 on page 13 correspond to the numbers in
Figure 5 on page 12.
