Table 13: SRX210 Services Gateway Voice Interface Port LEDs
DescriptionStateColorLED
Port is inactive.UnlitOffVoice Interface
LEDs
(FXS1, FXS2, FXO1,
and FXO2)
Port is connected and active.SteadyGreen
Port is active, but not ready for
data communication.
SteadyAmber
Port is active and data
communication is taking place.
BlinkingGreen
Port is initializing.
NOTE: The Voice Interface
port LEDs glow red (blinking)
while initializing. If there is an
error, the LEDs remain red;
otherwise, change to green.
BlinkingRed
Port has detected a hardware
initialization failure.
SteadyRed
Related
Documentation
SRX210 Services Gateway Specifications on page 7•
• SRX210 Services Gateway Front Panel and Back Panel Views (Low Memory, High
Memory, and PoE Versions) on page 10
• SRX210 Services Gateway with Integrated Convergence Services Front Panel and Back
Panel Views on page 12
• SRX210 Services Gateway Built-In Interfaces on page 14
• SRX210 Services Gateway Boot Devices and Dual-Root Partitioning Scheme on page 22
• SRX210 Services Gateway Cooling System on page 23
• SRX210 Services Gateway Power Supply on page 25
SRX210 Services Gateway Boot Devices and Dual-Root Partitioning Scheme
This topic includes the following sections:
•
Boot Devices on page 22
•
Dual-Root Partitioning Scheme on page 23
Boot Devices
The SRX210 Services Gateway can boot from two devices:
•
Internal NAND flash (default; always present)
•
USB storage key (alternate)
Copyright © 2010, Juniper Networks, Inc.22
SRX210 Services Gateway Hardware Guide
