• Installation Overview for the SRX210 Services Gateway on page 57
• SRX210 Services Gateway Cabinet Requirements on page 51
• SRX210 Services Gateway Rack Requirements on page 52
• Clearance Requirements for Airflow and Hardware Maintenance of the SRX210 Services
Gateway on page 53
General Site Guidelines for Installing the SRX210 Services Gateway
The following precautions help you plan an acceptable operating environment for your
SRX210 Services Gateway and avoid environmentally caused equipment failures:
•
For the cooling system to function properly, the airflow around the chassis must be
unrestricted. Allow sufficient clearance between the front and back of the chassis and
adjacent equipment. Ensure that there is adequate circulation in the installation location.
•
Follow the ESD procedures to avoid damaging the equipment. Static discharge can
cause components to fail completely or intermittently over time.
•
Ensure that the blank Mini-PIM panel is installed in the empty slot to prevent any
interruption or reduction in the flow of air across internal components.
NOTE: Install the device only in restricted areas, such as dedicated
equipment rooms and equipment closets, in accordance with Articles
110-16, 110-17, and 110-18 of the National Electrical Code, ANSI/NFPA 70.
Related
Documentation
SRX210 Services Gateway Specifications on page 7•
• SRX210 Services Gateway Safety Requirements, Warnings, and Guidelines on page 69
• SRX210 Services Gateway Cabinet Requirements on page 51
• SRX210 Services Gateway Rack Requirements on page 52
• Site Preparation Checklist for the SRX210 Services Gateway on page 49
• Clearance Requirements for Airflow and Hardware Maintenance of the SRX210 Services
Gateway on page 53
SRX210 Services Gateway Cabinet Requirements
The SRX210 Services Gateway can be installed in a standard 800 mm (31.5 in.) or larger
enclosed cabinet. Table 21 on page 52 provides the details on cabinet size, clearance,
and airflow requirements.
51Copyright © 2010, Juniper Networks, Inc.
Chapter 7: Preparing the Site for the SRX210 Services Gateway Installation
