Juniper SRX210 - HARDWARE GUIDE REV 3 - Pinouts; Interface Cable and Wire Specifications for the SRX210 Services Gateway

APPENDIX C
SRX210 Services Gateway Interface Cable
Specifications and Connector Pinouts
The network interfaces supported on the services gateway accept different types of
network cables.
This appendix includes the following topics:
•
Interface Cable and Wire Specifications for the SRX210 Services Gateway on page 155
•
RJ-45 Connector Pinouts for the SRX210 Services Gateway Ethernet Port on page 156
•
RJ-45 Connector Pinouts for the SRX210 Services Gateway Console Port on page 157
•
RJ-11 Connector Pinouts for the SRX210 Services Gateway with Integrated Convergence
Services FXO and FXS Ports on page 158
Interface Cable and Wire Specifications for the SRX210 Services Gateway
Table 48 on page 155 lists the specifications for the cables that connect to ports.
Table 48: Cable and Wire Specifications for Ports
Device
Receptacle
Maximum
LengthCable/Wire RequiredCable SpecificationPort
RJ-456 ft (1.83 m)One 6-ft (1.83-m) length
with DB-9/RJ-45
connectors
RS-232 (EIA-232) serial
cable
Console
port
RJ-45328 ft
(100 m)
One 15-ft (4.57-m)
length with RJ-45/RJ-45
connectors
CAT-5e (Category 5)
cable or equivalent
suitable for 100BASE-T
operation
Ethernet
port
Related
Documentation
RJ-45 Connector Pinouts for the SRX210 Services Gateway Ethernet Port on page 156•
• RJ-45 Connector Pinouts for the SRX210 Services Gateway Console Port on page 157
• SRX210 Services Gateway Front Panel and Back Panel Views (Low Memory, High
Memory, and PoE Versions) on page 10
155Copyright © 2010, Juniper Networks, Inc.
