DCE80-100E
Technical Handbook
Periodic supervision
Lubrication, Standard side-lift
7
P.Group 90
TDCE01
04GB
L = Lubricate
C = Check
Pos
No.
Description Interval No. of
lub.
points
Remark
500 1000
1 Sliding surfaces, length adjustment L Brush onto all sliding surfaces with the
attachment in the fully extended position
2 Sliding surfaces, sideshift L Brush onto all sliding surfaces with the sideshift
to the limit in each direction
3 Cylinders, sideshift L 2
4 Cylinders, length adjustment L 4
5 Locking cylinders L 4 Check that the sensors are undamaged and free
from grease. Check the function, see group 80.
6 Lifting pin twist connection L 4
7 Twist-lock L C 4 Disassemble and check the twist-locks every
5000 h. See group 80.
Same procedure should be used at suspected
damage to the twist-locks.
8 Contact pin L 4 Check that the sensors are undamaged and free
from grease. Check the function, see group 80.
9 Axel, hook coupling L 2 Disassemble and check the hooks every 5000 h.
See group 80.
Same procedure should be used at suspected
damage to the hooks.
