DCE80-100E
Technical Handbook
Periodic supervision
Lubrication, C-hook Side-lift
9
P.Group 90
TDCE01
04GB
L=Lubricate
C=check
Pos
nr
Benämning Intervall Antal
smörj-
pkt
Anm
500 1000
1
Cylinders, side locking plates
L4
Check that the sensors are free from grease
and that the sensor faces are undamaged
Check the function, see group 80
2
Cylinder, sideshift
L2
3
Cylinders, length adjustment
L4
4
Hooks
L2
Disassemble and check the hooks every 5000
h. See Technical Handbook group 80.
Same procedure should be used at suspected
damage.
5
Spring loaded contact pin, align-
ment against upper container
C2
Check that the sensors are free from grease
and that the sensor faces are undamaged
Check the function, see group 80
6
Spring loaded contact pin, align-
ment against lower container
C
Check that the sensors are free from grease
and that the sensor faces are undamaged
Check the function, see group 80
7
Cylinders, levelling
L4
8
Support wheels
LK4
9 Sliding surfaces, length adjustment L Brush onto all sliding surfaces with the sidelift
in the fully extended position
