ULTRAFLOW®54(H)/(J)
82
KamstrupA/S∙TechnicalDescription∙5512‐1554_J1_GB_04.2018
q
p
CCC
[m³/h] [imp/l] [l/imp] Divider DD [ms] [ms] (E=4) [ms] (E=5) [ms] (E=6)
0.6 116 300 3.9 ---Default
0.6 1 300 33 - 20 50 100
0.6 2.5 750 63 - - - 100
1.5 119 100 3.9
---
Default
1.5 1 100 33 - 20 50 100
1.5 2.5 250 63 - - - 100
1.5 10 1000 34 - - - 100
2.5 198 60 3.9
---
Default
2.5 1 60 33 - 20 50 100
2.5 2.5 150 63 - - - 100
2.5 10 600 34 - - - 100
3.5 151 50 3.9 ---Default
3.5 1 50 33 - 20 50 -
3.5 2.5 125 63 - - - 100
3.5 10 500 34 - - - 100
3.5 25 1250 64 - - - 100
6 137 25 3.9 ---Default
6 1 25 33 - 20 50 -
6 2.5 62.5 63 - - - 100
6 10 250 34 - - - 100
6 25 625 64 - - - 100
10 178 15 3.9
---
Default
10 1 15 33 - 20 50 -
10 10 150 34 - - - 100
10 25 375 64 - - - 100
15 120 10 3.9 ---Default
15 1 10 33 - 20 - -
15 10 100 34 - - 50 100
15 25 250 64 - - - 100
15 100 1000 35 - - - 100
25 179 6 3.9
---
Default
25 1 6 33 - 20 - -
25 10 60 34 - - 50 100
25 25 150 64 - - - 100
25 100 600 35 - - - 100
Meter factor Pulse duration
Table 28. Configuration variants of meter factor (DD) and pulse duration (E)
for Pulse Divider for ULTRAFLOW
®
54 and 34, qp 0.6…25.
