OPERATOR'S STATION
1-52
Front/Rear Wiper Switch
Operate wiper switch (1) to move the front and rear
windshield wipers.
IMPORTANT: The washer motor may become damaged
if washer fluid is continuously used for more than 20
seconds or the washer motor pump switch is operated
with no fluid in the washer tank. Take care about the
switch operation time and the fluid level in the washer
tank.
Do not operate the washer motor for too long and
keep the washer fluid at the correct level. In freezing
weather, use windshield washer solvent that will not
freeze.
: The front windshield wiper operates at fast speed.
:
The front windshield wiper operates at slow
speed.
INT :
The front windshield wiper intermittently
operates.
OFF :
The front windshield wiper stops moving and the
wiper blade is returned to the pre-start position.
:
Washer fluid squirts from the front nozzle and the
front windshield wiper operates.
:
Washer fluid squirts from the rear nozzle and the
rear windshield wiper operates.
: Rear windshield wiper operates.
: Washer fluid squirts from the rear nozzle.
1
MNEC-01-075
MNEC-01-076
MNEC-01-077
Rear Window Wiper Switch
Front Window Wiper Switch
Wiper Switch
Front
Washer
ON
Front Window Wiper Switch Rear Window Wiper Switch
MNDB-01-002
To Next Page
