OPERATING THE MACHINE
5-6
Lift Arm Height Kickout
The lift arm height kickout is a device that automatically stops
the lift arm at the preset position while raising the lift arm.
The lift arm height kickout works with a proximity switch (1) to
detect the position of lift arm.
NOTE: While lowering the lift arm, the proximity switch does
not work.
NOTE: The proximity switch is adjusted so that the arm stops
before reaching the highest raising position. To adjust the
position of this switch, consult your nearest authorized dealer.
Adjustment of Loader Front
The bucket can be stopped at the desired height by means of
optional lift arm auto leveler switches (1, 2), and at the desired
digging angle by means of the bucket auto leveler.
Adjust the bucket auto stop position according to the working
requirements.
Refer to the following sections for the procedures.
M4GB-05-002
1
To Next Page
