OPERATOR'S STATION
1-55
Declutch Position Switch
Declutch position switch (1) changes the function of left brake
pedal.
Operating declutch position switch (1) turns the declutch
function ON and OFF.
x Declutch ON
By depressing left brake pedal, the clutch is disengaged
and brake is applied without transmitting the drive
power to the tires.
: Declutch ON while lightly depressing the left
brake pedal: (Suitable for loading work on a level
surface.)
: Declutch ON while deeply depressing the left
brake pedal: (Suitable for work on a slope.)
x Declutch OFF
When depressing left or right brake pedal, brake is
applied while driving power is transmitting to the tires.
NOTE: When starting to ascend a slope, turn declutch
position switch (1) OFF (neutral), depress the left brake pedal.
Gradually release the left brake pedal while depressing the
accelerator pedal to easily start ascending the slope.
1
MNDB-01-003
ON OFF ON
1
MNDB-01-019
