MAINTENANCE
7-68
Dust Ejection Valve
--- daily
Clean
Dust ejection valve (1) is located on the bottom of air
cleaner (2).
Hold down the valve from both sides by using your fingers
until the end of dust ejection valve (1) opens.
If dust is difficult to be removed, loosen the clip at the root
of dust ejection valve (1) to remove dust ejection valve (1).
Clean inside the valve.
Check the valve for any damage.
MNDB-07-016
MNEC-07-120
80MNEC-07-120
1
2
1
Arrow View A
A
2
To Next Page
