KCM 70Z7 - Layout

MAINTENANCE
7-3
Layout
70Z7
1. Bolt on Cutting Edge
2. Bucket
3. Bucket Cylinder Pin
4. Bucket Cylinder
5. Front Combination Light
6. Hydraulic Oil Tank
7. Muffler
8. Air Cleaner
9. Reserve Tank
10. Radiator, Oil Cooler, and Other Cooling System
11. Work Light
12. Rear Combination Light
13. Batteries
14. Fuel Tank
15. Engine
16. Rear Axle
17. Rear Propeller Shaft
18. Transmission
19. Center Propeller Shaft
20. Steering Cylinder
21. Lift Arm Cylinder
22. Front Axle
23. Lift Arm Cylinder Pin
24. Lever (Bell Crank) Pin
25. Bucket Link Pin
26. Bucket Pin
1
26
25 24
23 22 21 20
19
18
17
16 15 14 13
12
11
10
9
8
7
6
543
2
MNDB-07-012
