KCM 70Z7 - Page 245

MAINTENANCE
7-4
Layout
70TM7
1. Bolt on Cutting Edge
2. Bucket
3. Bucket Cylinder Pin
4. Bucket Cylinder
5. Front Combination Lamp
6. Hydraulic Oil Tank
7. Air Cleaner
8. Muffler
9. Reserve Tank
10. Radiator, Oil Cooler, and Other Cooling System
11. Work Light
12. Rear Combination Lamp
13. Batteries
14. Fuel Tank
15. Engine
16. Rear Axle
17. Rear Propeller Shaft
18. Transmission
19. Center Propeller Shaft
20. Steering Cylinder
21. Lift Arm Cylinder
22. Front Axle
23. Lift Arm Cylinder Pin
24. Guide Pin
25. Bucket Pin
26. Bucket Link Pin
27. Bell Crank Pin
MNDB-07-027
2
34
6
9
10
5
12
13
141617
18
19
20
21
22
23
25
261
27
7
8
11
15
24
